Schmidt｜Street Sweeper｜Street King 660

A towed sweeping unit mounted on either the right or left with brake-back protection ensures direct and efficient collection of debris. The roller brush, which is optimally integrated into the suction shaft, enables a higher sweeping speed of 15% without impairing the sweeping result. A pneumatically operated coarse dirt cover is also provided for easy collection of larger debris. In the dual version, the machine can easily guarantee a sweeping width of 137.8 in with the simultaneous sweeping option.

The suction fans installed are transverse to the direction of travel in the front part of the hopper. This significantly reduces the overall length and enables an optimised air flow. Due to the low air resistance, a maximum suction capacity of 635,664 ft³/h is achieved.

Generously proportioned water tanks with a volume of 422.7 gal help to ensure long sweeping distances. Mounting the water tank at the rear helps to ensure a lower centre of gravity for better road handling. And, by not joining the water tanks to the hopper, we have achieved greater stability during tipping. Additional water tanks can be mounted between the driver’s cabin and the sweeping system to provide with up to 264.2 gal of additional capacity. At the same time, the auxiliary water tanks ensure noise reduction between the auxiliary engine and the driver's cab.

A particular highlight is the optional water volume control, which is accessible on the ES control panel and allows the water volume to be adjusted in three stages. Individual water jets can be activated and deactivated by touch command, helping to reduce water consumption considerably, extend sweeping times and conserve resources. All of these functions are accomplished without the need to route the water lines through the truck’s cabin.

The optional innovative pressurised water recirculation system can extend usage times by up to 30%. Waste water is channelled into the suction shaft using a separate waste water pump at the rear of the water tank, then sucked up again and re-treated. This helps to reduce the need for time-consuming water refills, reduce emissions of fine dust and particulate through better dust binding and keep the suction pipe permanently flushed to minimise blockages.

The large 9.2 yd³ hopper allows for the collection of large quantities of debris. The floor pan made from stainless steel and the rubberised baffle plates inside the hopper combine to ensure a lengthy service life and virtually no wear.

The fully integrated unit compartment for the hydraulic, pneumatic and electrical systems ensures quick and easy maintenance, with everything accessible from the outside through large covers. The baffle plates also act as sound proofing. The large tipping angle of 60° allows the hopper to be emptied fully, leaving no residue behind. A large, folding leaf screen is fitted over the entire width of the hopper.

The aerodynamic shape of the hopper, air flow and leaf screen produce a cyclonic effect inside the hopper to ensure maximum capacity utilisation and fewer emptying runs. An inspection cover on the side allows for additional inspection of the fill level inside the hopper.

Logical and intuitive menu navigation and automatically controlled processes help to support drivers when working by ensuring that concentration remains focused on the road ahead.

• Operating technology with a 7” colour touch screen
• Door control panel with joystick for basic functions
• Main functions can be controlled with one hand using the door control panel
• Audible and visual warning notifications
• Automatic display brightness adjustment (light sensor)
• On-board diagnostics
• Optional TFT monitor for up to three cameras

With the one- and two-engine variants, the Street King 660 offers consistent performance and maximum flexibility regardless of the drive concept. There is a choice between two drive variants - motor driven or hydrostatic drive - which means the customer's wishes can be individually catered for.

1. Motor driven

2. Hydrostatic drive

The hydrostatic drive concept offers excellent control throughout the entire sweeping operation and allows infinitely variable control of the travel speed between 0 and 15.5 mph. A high-resolution, TFT colour display enables easy operation, fast navigation and precise control of the hydrostatic drive with maximum comfort - even during long working operations.

The hydrostatic drive is the ideal drive concept for customers who want to operate without a superstructure engine. The hydrostatic unit is mounted between the transmission output and the rear axle differential. In sweeping mode, the mechanical drive is disconnected and the power flow is directed via the transmission output to the powerful hydraulic pump. This in turn drives the hydraulic motor, which drives the corresponding rear axle. At the same time, the hydrostatic transmission reliably supplies the sweeper body with the necessary power for all driving and sweeping situations.

The enclosed engine compartment combined with state-of-the-art engine technology has helped to make the Street King 660 one of the quietest and most environmentally friendly sweepers on the market. The auxiliary engine is highly efficient at supplying power and the engine compartment can be accessed with ease when the hopper is tilted.

Standard truck chassis either class 7 or 8 and a wheelbase of approx. 126 - 137.8 in, depending on the chassis and engine type. The sweeper is attached to a universal intermediate frame and not to the truck itself, leaving open the opportunity for the sweeper to be configured as a demo
